Asiga DentaGUIDE – 3D Surgical Guide Resin for Implant Dentistry
Earn 149 loyalty points
Référence: H103522
Livraison gratuite dès 198 €*
Paiement sécurisé - SSL
Livraison 24/48 h en France
Livraison 2 à 5 jours Europe
Paiement par virement
Paiement par chèque*
Paiement en 3 fois**
** Achat de 300 à 1100 € par prélèvement automatique - *Uniquement en France
Asiga DentaGUIDE - Clear 3D Printing Resin for Implant Surgical Guides (385 nm)
Brand : Asiga
SKU : H103522
Use : Surgical guide resin (digital implantology)
DentaGUIDE is a Class I biocompatible, rigid and high-clarity resin designed for implant surgical guide 3D printing. Optimized for 385 nm DLP / UV LED systems, it helps produce accurate positioning windows and drill guidance features for safe, repeatable guided surgery.
Clear High rigidity Class I biocompatible Autoclavable 121°C 385 nm ISO 13485
Key advantages for dental labs
- Clinical safety & precision: rigid material supports stable guide seating and accurate drilling paths.
- Excellent visibility: clear resin improves control during try-in and surgical positioning.
- Autoclavable at 121°C: enables reliable sterilization prior to surgery.
- Process repeatability: optimized for 385 nm workflows and consistent production.
- Quality & traceability: manufactured under ISO 13485.
Dental applications
- Implant surgical drill guides (sleeves, drilling windows, positioning features).
- Guides for gingivectomy and bone reduction.
- Digital implantology workflows for predictable guided surgery.
Goal: improve positioning accuracy, standardize the procedure and reduce intraoperative adjustments.
Pro tip: continuous resin mixing
For consistent mechanical properties and reliable print results, use a resin mixer.
Continuous mixing reduces sedimentation, improves repeatability, dimensional stability and surface quality—especially in 385 nm production workflows.
Recommended workflow
- Preparation: homogenize the resin (continuous mixing recommended).
- Printing: use validated 385 nm parameters (exposure, layer thickness, orientation).
- Cleaning: rinse in IPA and fully dry.
- Post-curing: follow the official DentaGUIDE IFU.
- Sterilization: autoclave 121°C per protocol, then inspect the guide.
Videos — laboratory process
Technical specifications
| Material type | Biocompatible dental resin for 3D printing surgical guides |
|---|---|
| Indication | Implant surgical guide (digital guided surgery workflow) |
| Medical class | Class I |
| Shade | Clear / Transparent |
| Wavelength | 385 nm |
| Quality / manufacturing | Asiga — ISO 13485:2016 |
| Sterilization | Autoclave 121°C |
| Packaging | 1 bottle — 1 L |
Regulatory compliance
- United States: FDA listed (as applicable for the material range).
- European Union: CE marked under MDR (as applicable for the material range).
- Canada: Medical Device licensing (as applicable).
- Australia: ARTG listing (as applicable).
Note: always follow the official IFU and your local regulatory requirements for medical devices.
Documents & resources
Delivery
Delivery: Asiga DentaGUIDE clear surgical guide resin — 1 liter bottle.
Technical FAQ (dental laboratory)
Which 3D printers are compatible with DentaGUIDE?
DentaGUIDE is designed for Asiga printers and compatible with other 385 nm DLP / UV LED systems.
For surgical accuracy (sleeves and positioning windows), validate exposure, layer thickness and orientation on your specific machine.
After printing, perform a controlled IPA wash, complete drying, then post-cure strictly according to the IFU to reach final properties.
Document your parameters to ensure repeatability across batches and technicians in a production environment.
For surgical accuracy (sleeves and positioning windows), validate exposure, layer thickness and orientation on your specific machine.
After printing, perform a controlled IPA wash, complete drying, then post-cure strictly according to the IFU to reach final properties.
Document your parameters to ensure repeatability across batches and technicians in a production environment.
Can DentaGUIDE be sterilized in an autoclave?
Yes, DentaGUIDE is autoclavable at 121°C when processed according to the official protocol.
A complete post-cure is essential before sterilization, as it stabilizes the material and supports long-term performance.
After sterilization, inspect fit and transparency, and store the guide in clean, protected conditions prior to surgery.
A complete post-cure is essential before sterilization, as it stabilizes the material and supports long-term performance.
After sterilization, inspect fit and transparency, and store the guide in clean, protected conditions prior to surgery.
What best practices ensure maximum drilling accuracy?
Maintain resin homogeneity (continuous mixing helps), avoid overexposure, and place supports strategically away from critical drill features.
Control minimum wall thickness as recommended in the IFU, and verify sleeve geometry after post-curing.
A standardized workflow (print + wash + dry + cure) reduces variation and improves consistency for guided surgery cases.
Control minimum wall thickness as recommended in the IFU, and verify sleeve geometry after post-curing.
A standardized workflow (print + wash + dry + cure) reduces variation and improves consistency for guided surgery cases.
Why do certifications matter for a dental lab?
Certifications and ISO 13485 manufacturing reinforce traceability, documentation and process consistency for medical devices.
For labs, this supports audits, case records, and predictable outcomes when producing surgical guides for clinics.
The key is to follow the IFU and keep a stable validated workflow to maintain clinical reliability over time.
For labs, this supports audits, case records, and predictable outcomes when producing surgical guides for clinics.
The key is to follow the IFU and keep a stable validated workflow to maintain clinical reliability over time.
